Power 70V (RMS) | 150W x 4 (One Channel Driven) - 135W x 4 (All Channel Driven) |
Power 100V (RMS) | 150W x 4 (One Channel Driven) - 135W x 4 (All Channel Driven) |
Input Sensitivity (Limiter Off) | 0.9 - 1.1V (+0/-1dBv) |
Input Impedance | 20KΩ balanced or 10KΩ unbalanced |
Frequency Response | 100Hz~15KHz (+0/-3dB) (At 10dB Below Output Power) |
Voltage Gain (100V) | 40 (+0/-1dB) |
THD + N | <0.1% (Ref. 1KHz 1/8 Rated Power, A-Weighted) |
S/N Ratio | >95dB (Ref. Rated Power, A-Weighted) |
Crosstalk (Below Rated Power) | >70dB |
Damping Factor (1KHz, 8W) | >200 |
Power/Output Circuity | Switching Power Class-D |
Protections | Full short circuit, open circuit, thermal, ultrasonic, and RF protection stable into reactive or mismatched loads, turn ON/OFF, muting, tried crowbar. |
Controls | Front: On/Off Power Switch, Volume Channel A, B / Rear 70/100V selector |
Indicators | SIGNAL: 4 green LED - CLIP & PROTECTION 4 red LED / POWER: 1 green LED |
Connectors | Inputs: Euro Block - Outputs: Euro Block |
Power Supply | AC: 110-120V or 220~240V 50/60Hz |
Dimension (HxWxD) | 44 x 483 x 360 mm / 1.73" x 19.02" x 14.17" |
Weight | 5.4 kg / 11.91 lbs |
